Hardware accessories of glass curtain wall engineering

In our life, we often use complex glass products, such as glass curtain wall, glass glasses, glass moving doors, etc. Ryukyu Qiong products are both beautiful and practical, which can not only with halo Ying unique appearance attractive, and can make full use of its hard physical performance. Some art glass will even give the glass more patterns and enhance the decorative effect. We will introduce the accessories of the open frame glass curtain wall, and the structural forms of the common glass curtain wall.


-. What hardware accessories are required for glass curtain wall engineering
1. After the early installation, the supplementary curtain wall panel (if there are embedded parts) will use chemical anchor bolts and expansion bolts. A set of agents, rods, flat pads, and nut expansion bolts have flat pads, elastic pads and nuts.
II. Install glass vertical aluminum keel; generally connected with steel transfer joint, isolated between steel transfer joint and aluminum keel, generally connected through screw connection with M12 stainless steel screw, and calculate the size of two flat, one bullet and one nut.
Three, crossbeam installation, generally fixed by angular aluminum using a screw, generally with MG stainless steel screw.With two flat, one bullet and one nut.
Four, if it is a hidden frame glass curtain wall, then install glass will be used to glass block fixation method. General conventional glass curtain wall used hardware for these (except point glass).

I. According to the form of glass curtain wall:
1, open frame glass curtain wall: metal frame components exposed in the frame support glass curtain wall on the outer surface of the panel.
2, hidden frame glass curtain wall: The components of the metal frame are not exposed to the frame support glass curtain wall on the outer surface of the panel.
3, semi-hidden glass curtain wall: transverse or vertical components of the metal frame are the frame supported glass curtain wall exposed on the outer surface of the panel.
II. According to the curtain wall installation method:
1, component type glass curtain wall: frame supported glass curtain wall for column, beam and glass panel on site.
2, assembled panels and metal frames (columns, beams) into curtain wall units.The frame supporting glass curtain wall is installed on the site in the form of a curtain wall unit.
III. Curtain wall is divided into materials: commercial curtain wall, stone curtain wall, metal curtain wall, concrete curtain wall and combined curtain wall.
Common form of glass curtain wall structure. Classification of hidden frame, semi-hidden frame, open frame, point type, full glass and other stone curtain wall: short groove type stone curtain wall, open groove type stone curtain wall, steel pin type stone curtain wall, back bolt type stone curtain wall.
