EN39 Scaffolding Pipe

EN39 Scaffolding Pipe


Brief introduction

We are the EN39 scaffolding pipe supplier.We have EN39 scaffolding pipe and a series of practically complete pipe specifications for your choice.

Consultation & Contact
Detailed parameters
Product name EN39 Scaffolding Pipe
Technique Longitudinal Electronic Resistance Welding(ERW)
Size Diameter W.T Length
48.3 3.2 6M/6.4M
48.3 4.0 6M/6.4M
Surface hot dipped galvanized,black
Zinc coating 200-600g/m2
Ends Plain ends
Packing In bundle or bundle then wrapped with PVC
Inspection With Chemical Composition and Mechanical Properties Testing;Dimensional and Visual Inspection, With Nondestructive Inspection
Certification ISO9001
Application Urban construction pipe, Scaffolding pipe, Building material tube, etc
Trade Terms FOB, CFR, CIF, EXW, etc.
Payment L/C, T/T,Western Union
Delivery Time Usually within 10-30 days after receipt of deposit
Loading Port Xingang , Tianjin


Chemical Composition and Mechanical Properties of EN39 Scaffolding Pipe

Chemical Composition and Mechanical Properties
Steel grade Chemical composition (cast analysis) ,  in %,by mass Mechanical properties
C          max. Si Mn     max. P      max. S      max. Al      min. Yield strength ReH        min      MPa1 Tensile strength   Rm                 MPa1     Elongation  A             min          %
Steel    name Steel number
S235GT 1.010 6 0.2 a,b 1.4 0.040 0.045 0.020 235 340/520 24
a.≤0.05%(range 1)(≤0.04% if option 2 is specified) or ≥0.15%≤0.25%(range2). b.When bare tubes are specified (see option 8) the range shall be reported at the time of enquiry and order.
