Aluminum Glass Window Curtain Wall System for building exterior Detail Dwg

Aluminum Glass Window Curtain Wall System for building exterior Detail Dwg

Quality Warranty:More than 5 Years, 20years

Surface Treatment:PE Coated, PVDF Coated

Panel thickness:2mm, 3mm,4mm,5mm,6mm

Aluminum thickness:0.15mm to 0.50mm

Width:1000mm to 1575mm

Length:2000mm/2440mm/6000mm

Color:depends on customer’s requirements

Glass Thickness:6mm-40mm

Normal sizes: ①4mm heat strengthened+0.76pvb+4mm heat strengthened green+6A+4mm low-E heat strengthened+0.76pvb+4mm heat

Strengthened:②4mm heat strengthened+0.76pvb+4mm heat strengthened green+6A+4mm low-E heat strengthened+0.76pvb+4mm frosted heat strengthened ③6mm frosted heat strengthened

Product advantage:

1.Light weight,quick and easy to install

2.Excellent rigidity and impact resistance

3.Environmental protection and energy saving

4.Easy for clean and maintenance

Packaging Details:

The normal package is Iron pallets (Size: L*W*H)+ Air bag + PE Film

1) If export to European countries, the timber reveals will be fumigated.

2) If container is too tiger, we will use PE film for packing or pack it according to customers special request.
